MetecnoSpan® by Bondor®

By Institute Library posted 15 Sep, 2021 19:05

MetecnoSpan® by Bondor®.jpg

Product Details

MetecnoSpan® by Bondor®
MetecnoSpan® is a roofing system that combines the roofing, insulation and ceiling in one roof panel with a fire-retardant polyisocyanurate (PIR) core. MetecnoSpan is capable of long spans and high thermal performance and is used mainly in commercial and industrial roofing applications.

MetecnoSpan comes in various PIR core thicknesses 40, 60, 80 and 100mm and delivers a Total R-value of 2.10, 3.05, 4.00, 4.94 for insulation average temperature of 15˚C.

Key Features
• Available Core PIR
• Standard Width 1000mm
• Standard Length Up to 25m
• External Material BlueScope COLORBOND® Steel 0.42mm
• External Finish Trapezoidal Profile
• Exterior Colour Surfmist®
• Internal Material BlueScope COLORBOND® Steel 0.5mm G300
• Internal Finish Plain, Fineline, Satinline, V Rib
• Interior Colour Surfmist®
• Pitch 2 degrees
• CODEMARK™ Accredited CM40183
• Bushfire Attack Level BAL-40 (all exposed core to be covered with flashing)
• Material Group Numbers C1.10 Group 2a
• FM Approval 4471
• 4880
• 4881
• Ignitability Index 0
• Spread of Flame Index 0
• Heat Evolved Index 0
• Smoke Index 1
• SMOGRARC <100

Advantages
• Meets Section J Thermal Requirements
• Long Spans
• Low Pitch and compatible with Bondor_Metecno SecureLap system

Project Applications
• Retail & Shopping Centre Roofs
• Commercial
• Agricultural
• Warehouses
• Industrial
• Any owners requiring FM Approval and FM Global Insurer approved roofing systems
