Econoclad®

Product Details

Econoclad®
EconoClad® is a high performing and low-cost roofing or walling insulated panel suitable for industrial and commercial cladding. EconoClad has a non-ozone depleting fire-retardant PIR core bonded between a hi-tensile COLORBOND® steel roof with multi options facings on the internal side.

EconoClad has various thickness from 25, 40, 60, 80, 100mm delivering a Total R-value of 1.50, 2.22, 3.17, 4.12, 5.06 at 15˚C.

Key Features
• Available Core PIR
• Standard Width 1000mm
• Standard Length Up to 16m
• External Material BlueScope COLORBOND® Steel G550 0.42mm
• External Finish High Rib Trapezoidal Profile
• Exterior Colour Surfmist®
• Internal Material Lightweight Thermal Foil, Fibreglass, PVCc
• Internal Finish Foilback, Embossed PVCc
• Interior Colour Bright White, Silver, Black
• Pitch 2 degrees
• CODEMARK™ Accredited CM40234
• FM Approval 4880b
• Bushfire Attack Level BAL-40 (all exposed core to be covered with flashing)
• Material Group Numbers C1.10 Group 2a
• Ignitability Index 0
• Spread of Flame Index 0
• Heat Evolved Index 0
• Smoke Index 1
• SMOGRARC <100

Advantage
• Economical
• Practical roof or walling solutions
• Faster to install
• Alternative to bulk insulation and roof insulation systems
• Offers high performance roofing material satisfying Section J requirements

Project Applications
• Perfect for Asbestos roof replacements
• Warehouse roofing
• Shed Roofing
• Chicken Shed
• Storage Facilities
• Industrial Shed Roofing
• Agricultural Roofing
