SolarSpan

Product Details

SolarSpan® by Bondor®
SolarSpan® is Australia’s leading insulated roofing panel offering long-span, low pitch and high thermal efficiency to satisfy Section J requirements in commercial and residential applications. Insulated roof panel system combines roofing, EPS-FR insulation and pre-painted ceiling in one durable function and attractive roof panel. SolarSpan insulated roofing is faster to install than conventional roofing, eliminating the need for additional structural supports and trades.

SolarSpan offers various EPS-FR core thicknesses in 50mm, 75mm, 100mm, 125mm, 150mm, 175mm and 200mm and delivers a Total R-value of 1.40, 2.03, 2.65, 3.27, 3.90, 4.52, 5.15 for insulation average temperature of 15˚C.

Key Features
• Available Core EPS-FR
• Standard Width 1000mm
• Standard Length Up to 24m
• External Material BlueScope COLORBOND® Steel G550 0.42mm
• External Finish High Trapezoidal Profile
• Exterior Colour Classic Cream™, Surfmist®, Paperbark®, Shale Grey™, Dune®, Pale Eucalypt®, Manor Red®^, Basalt®^, Woodland Grey®^
• Internal Material BlueScope COLORBOND® Steel 0.6mm G300
• Internal Finish Plain, VJ
• Interior Colour Surfmist®, Classic Cream™
• Pitch 2 degrees
• CODEMARK™ Accredited CM40145
• Bushfire Attack Level BAL-40 (all exposed core to be covered with flashing)
• Material Group Numbers C1.10 Group 1 & 2a
• Ignitability Index 0
• Spread of Flame Index 0
• Heat Evolved Index 0
• Smoke Index 2-3
• SMOGRARC <100

Advantages
• Meets Section J Thermal Requirements
• Long Spans
• Low Pitch and compatible with Bondor_Metecno SecureLap system

Project Applications
• Retail & Shopping Centre Roofs
• Commercial
• Agricultural
• Warehouses
• Industrial
