LuxeWall® by Bondor®

By Institute Library posted 12 Sep, 2021 15:13

LuxeWall

Product Details

LuxeWall® by Bondor®
LuxeWall® is a modern, lightweight residential wall cladding solution developed with a concealed fixing system to fasten to timber and metal stud wall framing. The system uses architectural SL Grade steel faced insulated wall in a vertical orientation.

LuxeWall is available in two core thicknesses 50 and 75mm. LuxeWall® delivers Total R-value of 1.9, 2.5 for insulation average temperature of 15˚C.

Key Features
• Available Core EPS-FR with CorePlus®
• Standard Width 1200mm, 900mm* (*non-standard)
• Length Up to 6.5m
• External Material BlueScope COLORBOND® Steel 0.6mm G300
• External Finish Plain, VJ
• Exterior Colour Options Metallic Cosmic®, Metallic Astro®, Matt Basalt®, Matt Surfmist®
• Internal Material BlueScope COLORBOND® Steel 0.6mm G300
• Internal Finish Plain
• Interior Colour Options Surfmist®
• CODEMARK™ Accredited CM40203
• Bushfire Attack Level BAL-40 (all exposed core to be covered with flashing)
• Paint System AS/NZS 2728 & AS1397
• Ignitability Index 0
• Spread of Flame Index 0
• Heat Evolved Index 0
• Smoke Index 2-3
• SMOGRARC <100

Advantages
• Concealed UniSmart architectural trim and capping for windows and door openings
• Cost effective Architectural cladding solution
• Use of trending Architectural Matt & Metallic colour finishes.
• Helps meet local council and developer covenants in a single product
• Light weight cladding technology
• Offers high performance insulation solutions

Typical Applications
• Multi -Residential
• Commercial
• Insulated Wall
• Home Improvements
• Architectural
• Home Renovations
• Modular Buildings
• Residential
