InsulRoof® by Bondor®

By Institute Library posted 12 Sep, 2021 10:16

InsulRoof® by Bondor®v2

Product Details

InsulRoof® by Bondor®
InsulRoof® is a long-spanning insulated roof panel that features a corrugated roof profile and a pre-finished steel ceiling lining encased in a dual layered insulating core technology comprising of EPS-FR and PUR. SupaCore® is a world-first insulating core technology developed by Bondor® to deliver dual layers of high-performance insulation and bonding strength.

InsulRoof® is available in a range of core thicknesses 50, 75, 100, 125, 150, 200mm InsulRoof® delivers Total R-value of 1.61, 2.23, 2.85, 3.48, 4.10, 5.35 for insulation average temperature of 15˚C.

Key Features
• Available Core EPS-FR and PUR
• Standard Width 1000mm
• External Material BlueScope COLORBOND® Steel 0.6mm G300
• External Finish Corrugated
• Exterior Colour Classic Cream™, Surfmist®, Paperbark®, Shale Grey™, Dune®, Pale Eucalypt®, Manor Red®^, Basalt®^, Woodland Grey®^, Zincalume™
• Internal Material BlueScope COLORBOND® Steel 0.6mm G300
• Internal Finish Plain, VJ
• Interior Colour Classic Cream™, Surfmist®
• Pitch 5-degrees min.
• CODEMARK™ Accredited CM40235
• Bushfire Attack Level BAL-40 (all exposed core to be covered with flashing)
• Material Group Numbers C1.10 Group 1 & 2
• Ignitability Index 0
• Spread of Flame Index 0
• Heat Evolved Index 0
• Smoke Index 1
• SMOGRARC <100

Advantages
• Long Span
• Easy installation eliminating trusses, mesh, sarking, insulation & plasterboard
• Cost Effective
• Tried and tested in cyclonic regions

Typical Applications
• Carports & Patios,
• Gazebos
• Multi and Singular Residential Roofs
• Commercial and Industrial Roofs
