Equitilt FlameGuard® by Bondor®

By Institute Library posted 08 Sep, 2021 20:39

Product Details

Equitilt FlameGuard® by Bondor®
Equitilt FlameGuard® is a non-combustible architectural walling panel system manufactured with a mineral wool (MW) fibre core material. These panels are recommended to be used where improved fire performance is required for insurance purposes in walling applications.

Equitilt FlameGuard is available in core thickness of 50, 75mm & FlameGuard® Plus is available in 100, 150mm delivering a Total R-value of 1.58, 2.29, 3.00, 4.41 for insulation average temperature of 15˚C.

Key Features
• Available Core MW
• Standard Width 1200, 1140*, 900mm* (*non-standard)
• External Material BlueScope COLORBOND® Steel 0.6mm, 0.7mm G300
• External Finish Plain, Ribbed, Satinline, Shadowline Series 600/1200
• Exterior Colour Stand. & Non-Stand. COLORBOND® colours
• Internal Material BlueScope COLORBOND® Steel 0.6mm, 0.7mm G300
• Internal Finish Plain, Ribbed, Satinline, Shadowline Series 600/1200
• Interior Colour COLORBOND® Intramax™.
• CODEMARK™ Accredited CM40149
• Bushfire Attack Level FlameGuard®: BAL-40
• FlameGuard® Plus: BAL-FZ (All exposed core to be covered with flashing)
• Material Group Numbers C1.10 Group 1
• FM Approval FlameGuard®: 4880 No Height Restrictions
• FlameGuard® Plus: 4880 & 4881 No Height Restrictions
• Combustibility Non-Combustible
• Ignitability Index 0
• Spread of Flame Index 0
• Heat Evolved Index 0
• Smoke Index 3
• SMOGRARC <100

Advantages
• Fire Rated walling product
• Certified to achieve up to a 3-hour fire rating
• Cost effective
• Suited for Non-Combustibility, FRL or FM Approval for insurance purposes

Typical Applications
• Architectural
• Sustainable Buildings
• Retail and Showroom Premises
